RCBO - Standard DSCEACSN2100020 20A SPN Residual Current Circuit Breaker with Overload and Short Circuit Protection Online

Standard RCBO is a single composite device which provides protection against over currents and earth leakage faults in the same and DSCEACSN2100020 the current rate is 20A SPN Residual Current Circuit Breaker with Overload and Short Circuit Protection.It have features is width Pulsating DC protection-TypeA  ,Discrimination nusing time delay-Types RCBO  and Controlled response VD RCBO , Protection in case of loss of supply neutral ,Enhanced immunity to nuisance tripping.The Positive contact indication is  Red for ON , Green for OFF Short circuit breaking capacity 10 kA , Large terminal capacity is RCBOs have 35 mm2 for cool running while in operation.It  range is 6A, 10A, 16A, 20A, 25A, 32A & 40A. It rated Residual Operating Current  is 30, 100, 300mA. Instantaneous Tripping Current is  ‘C ’curve. It voltage is 240V. Insulation Voltage is 660V.The frequency is 50Hz.The number of poles is 1P+N. The Short Circuit Capacity is 10kA.It rated Residual Making Breaking Capacity is 500A. Its weight 0.420. It vibration resistance is 3g.

 Buy Standard DSCEACSN2100020 20A SPN Residual Current Circuit Breaker with Overload and Short Circuit Protection Online :
